Tuesday, December 20, 2016

J.W. WINCO NOW OFFERS STEEL, ALUMINUM, OR STAINLESS STEEL SPLIT SET COLLARS WITH ADJUSTABLE HAND LEVER

J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now has available GN 706.4 Steel, Aluminum, or Stainless Steel Split Set Collars in metric sizes with Adjustable Hand Levers for tool-less clamping.
GN 706.4 Steel
The split set collars can safely and simply be assembled with high clamping forces via the adjustable lever without damaging the surface of the shaft the collar is being mounted on. With a shaft tolerance that should be within h11, these RoHS compliant set collars not only serve as an end stop, but they can also be used for fixing or triggering other components such as end limit switches.

Also available in stainless steel and aluminum, the steel version body is made from sintered steel with black oxide finish. The handle of the adjustable hand lever is zinc die-cast, with a black electrostatically applied powder coat finish, the insert and screw are stainless steel.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s website catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com.

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail at sales@jwwinco.com.

Tuesday, December 6, 2016

J.W. WINCO OFFERS ZINC DIE-CAST HOOK-TYPE LATCHES LOCKABLE

NEW BERLIN, WI – J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now offers GN 115.8 Zinc Die-Cast Hook-Type Latches Lockable.
GN 115.8
These RoHS compliant hook-type latches with hook and latch bracket are mainly used for sliding doors and flaps. The locking action is in radial direction to the axis of rotation, resulting in a wide variety of different uses. Two keys are supplied with the unit, and the key can be removed in both end positions. The latches are supplied with the hook enclosed loose, while hook-type latches with other latch distances or other pivoting ratios are available upon request.

The latch housing is zinc die-cast, while the locating ring is zinc die-cast, chrome plated or with a black powder coated textured finish. The latch hardware is steel, zinc-plated, while the key is nickel silver with plastic hand piece and the T-handle grips are matte black nylon plastic.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s website catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com.

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail at sales@jwwinco.com.

Tuesday, November 22, 2016

STEEL LEVELING SETS WITH SPHERICAL WASHER NOW AVAILABLE FROM J.W. WINCO


NEW BERLIN, WI – J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now has available GN 350.2 Steel Leveling Sets with Spherical Washer.

GN 350.2The leveling sets, made from steel, have a zinc-plated, and blue passivated finish, are used for leveling, adjusting, and linking operations.

The RoHS compliant leveling sets, which are also available in stainless steel, consist of a threaded upper sleeve and a tapped lower sleeve. The fine thread allows precise, step-less setting and locking using a hook wrench. An anti-rotation disk also serves as a height limiter for the maximum height. The spherical washer allows precise installation of two non-parallel planes at a required gradient up to ~4°. Normally this screw is permanently and securely locked by the static load created when the mounting screw is tightened. If this is not sufficient, the use of a locknut is recommended.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s website catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com.

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail at sales@jwwinco.com.

Tuesday, November 15, 2016

J.W. WINCO OFFERS STEEL HORIZONTAL ACTING TOGGLE CLAMPS WITH SAFETY HOOK LATCH, WITH VERTICAL MOUNTING BASE


NEW BERLIN, WI -- J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now offers GN 820.4 Steel Horizontal Acting Toggle Clamps with Safety Hook Latch, with Vertical Mounting Base.

GN 820.4 These RoHS-compliant horizontal acting toggle clamps, which are also available in stainless steel, have a safety function whereby, during closing, a spring loaded safety hook latch ensures a secure locking connection. It prevents the inadvertent unlocking of the clamp due to vibrations or an accidental attempt of loosening or opening of the clamp.

To open and release the clamp, users pull up on the finger grip to disengage the safety hook latch mechanism, allowing for one hand operation. As the lever and clamping bar move in the opposite direction, they require less space for the clamping action.

The toggle clamp and safety hook latch are made from case-hardened sheet metal, zinc plated, with a blue passivated finish. The bearing pins are tempered, while the bearing rivets are case-hardened, and all moving parts are lubricated with special grease. The hand grip is constructed of a high quality, oil resistant red plastic. The spindle assembly has a threaded stud made of steel, zinc-plated, with a blue passivated finish, and the spindle tip is black neoprene rubber.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s Web site catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com.

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail at sales@jwwinco.com.

Tuesday, October 25, 2016

J.W. Winco Now Offers Zinc Die-Cast Indexing Plunger Latch Mechanisms with Rest Position


NEW BERLIN, WI – J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now has available GN 417 Metric Size Zinc Die-Cast Indexing Plunger Latch Mechanisms with Rest Position.

GN 417The RoHS compliant indexing plunger latch mechanisms are used for applications where the plunger has to stay in its retracted position. To achieve this, the knob is rotated by 90 degrees after being retracted, as a notch keeps the plunger in this position. The design of the holes / slots allows for fixed or adjustable mounting of the latch mechanism base onto Tubing or T-slot aluminum structures. A receptacle for the Indexing Plunger Latch Pin with adjustable slots in the base is also available upon request.

The plunger housing is zinc die-cast, with a black plastic coated textured finish, while the plunger pin and spring are stainless steel. The pull knob is constructed from a matte black glass fiber reinforced nylon plastic, which is not removable.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s website catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com.

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail at sales@jwwinco.com.

Thursday, October 13, 2016

J.W. Winco Now Offers Technopolymer Plastic Hollow Knurled Knobs with Stainless Steel Threaded Stud

NEW BERLIN, WI -- J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now offers GN 421.12 Metric Size, Technopolymer Plastic Hollow Knurled Knobs with a Stainless Steel Threaded Stud and Swivel Thrust Pad.

Temperature resistant to 194° F (80 °C), the RoHS compliant hollow knurled knobs have a ball end whose diameter is smaller than the core diameter of the thread. The thrust pad, which is made of black technopolymer plastic with a matte finish, supplied unmounted, and allows for a swivel of 15°, is easily clipped on and taken off. In clamping applications, the partially protruding steel hub of the knurled knob prevents chipping of the plastic of the knob base.

The knob body is a black technopolymer plastic with a smooth, glossy finish, while the threaded stud is 304 Cu stainless steel, molded-in.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s Web site catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com.

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail atsales@jwwinco.com.

Tuesday, September 27, 2016

Aluminum Torque Limiting Knurled Knobs with Steel Hub Available from J.W. Winco

NEW BERLIN, WI – J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now has available GN 3663 Metric Size, Aluminum Torque Limiting Knurled Knobs with Steel Hub.

These knurled knobs are used when manually applied torque is to be limited. When turned clockwise,
the torque mechanical system of the knurled knob triggers an "over-engagement" as soon as the specified torque is reached. When tightening, this insures that maximum permissible torque is not exceeded. When turned counter-clockwise, loosening the knob mechanism, the mechanical system locks so that the torque is not limited. Torque necessary for release will always be transmitted properly. After removal of cover and loosening of the countersunk screw, the tapped or threaded stud insert can be dismantled. In addition, versions with inch size tapped holes or threaded studs are available upon request.

The body of these RoHS compliant knobs is aluminum, with a black anodized finish, while the torque mechanism is steel with a blackened finish and the cover cap is plastic with a light gray matte finish.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s website catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com.


For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail at sales@jwwinco.com.

Tuesday, September 13, 2016

Stainless Steel Vertical Acting Toggle Clamps With Vertical Mounting Base Available From J.W. Winco

NEW BERLIN, WI – J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now offers GN 810.1 “Universal Fit” Steel Vertical Acting Toggle Clamps with Vertical Mounting Base.

The toggle clamp is case-hardened sheet metal, zinc plated, with a blue passivated finish. The bearing pins are tempered, the hand grip is a high quality, oil resistant red plastic, and the neoprene spindle assembly has a steel, zinc plated threaded stud in a blue passivated finish.

These RoHS compliant vertical acting toggle clamps work according to the toggle principle, as the lever and clamping bar move in the same direction. In the clamped position, the operating lever is in its vertical position. The vertical acting toggle clamps in the U-bar version with two flanged washers can accommodate an application specific clamping screw. A version including the spindle assembly with neoprene rubber tip is available as a standard. A modified version of the toggle clamp can be utilized by welding the clasp, which can then accommodate an application specific hold-down fastener component. The “Universal Fit” base allows for both inch and metric hole pattern mounting.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s website catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com.

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail at sales@jwwinco.com.

Tuesday, August 30, 2016

Stainless Steel Vertical Acting Toggle Clamps With Horizontal Mounting Base Available From J.W. Winco


NEW BERLIN, WI – J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now has available GN 810 “Universal Fit” Stainless Steel Vertical Acting Toggle Clamps with Horizontal Mounting Base.

GN 810
These vertical acting toggle clamps work according to the toggle principle, as the lever and clamping bar move in the same direction. In the clamped position, the operating lever is in its vertical position. The RoHS compliant vertical acting toggle clamps in the U-bar version with two flanged washers can accommodate an application specific clamping screw. A version including the spindle assembly with neoprene rubber tip is available as a standard. The “Universal Fit” base allows for both inch and metric hole pattern mounting.

All the toggle clamp’s moving parts are lubricated with a special grease. The hand grip is made from a high quality, oil resistant red plastic.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s website catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com.

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail at sales@jwwinco.com.

Tuesday, August 16, 2016

J.W. Winco, Inc. Offers Stainless Steel Arched Pull Handles

J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now offers GN 565.9 Stainless Steel Arched Pull Handles, Tapped or Thru Hole.

These RoHS-compliant Arched Pull Handles are made of 304 stainless steel and feature a matte shot-blast finish. The modernly designed handles are suitable for door or drawer applications on medical, pharmaceutical, packaging and any other equipment that requires them to endure corrosion-free environments. The thru hole version accepts 10-32 UNC and 10-24 UNC inch size socket cap screws and metric size M5 (DIN 912) socket cap screws. The tapped version accepts an M6 x1.0 pitch fastener of choice. In addition, various inch and metric size fasteners and kit packaging are available upon request.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s website catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com.

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail at sales@jwwinco.com.

Wednesday, August 10, 2016

J.W. Winco: A Family Tradition Of Machine Component Expertise (American Fastener Journal)

J.W. Winco, Inc. was established in May of 1978, with its international headquarters located in New Berlin, Wisconsin. Winco became a part of the Otto Ganter GmbH & Co., KG (Germany) group of companies in 2009, a prominent global manufacturer that allowed Winco to greatly enhance its manufacturing and distribution capabilities in the standard machine components and assembly hardware industry. J.W. Winco Canada, Inc., opened in 2011 in Mississauga, Ontario, to more directly serve customers in Canada, and in 2014, the company once again expanded its coverage area by opening an office in Mexico City, Mexico.

J.W. Winco offers an extensive selection of modernly designed, ergonomically shaped standard components for the industrial and commercial equipment industries.
J.W. Winco management team (left to right): Robert Winkler, John Winkler Jr. and Mark Winkler.
“Our product line represents a 21st century look, function, and feel,” said John Winkler Jr., J.W. Winco chief executive officer and member of the office of the president. “With more than 25,000 items in stock, we have the ability to ship the majority of orders received within 24 hours. Our mission is to provide our customers with the most comprehensive selection of quality metal and plastic, metric- and inch-size standard machine components, hand operating and assembly hardware available in the marketplace and be their ‘#1 Source’ for those small, but critical, items.”

John Jr., who has been involved in the family business since shortly after it was founded by his parents, shares the office of the president with his two brothers and is mainly responsible for sales and marketing. Mark, who joined the company full time in 1992, is chief financial officer in charge of finance, operations, purchasing, and personnel. Robert, who came aboard in 1994, added his engineering expertise as chief technology officer, covering engineering, manufacturing, and information technology.

The company began modestly while John Jr. Was still working for another packaging machinery company owned and operated by his parents. One day, while sourcing machine component parts, he pointed out to his father that other businesses must Need these similar components if their company did. The distributorship then evolved from his office desk. Today, J.W. Winco serves customers throughout the United States, Canada, Mexico, Europe, and the Far East. Most are original equipment manufacturers, with products ranging from the packaging machinery industry to the medical equipment industry and makers of construction equipment.

J.W. Winco offers online shopping in its eStore, as well as 2D and 3D CAD.

“We strive to provide design engineers, project engineers, purchasing agents, and others involved in the product selection process the largest variety of products and technical information available in our industry,” John Winkler Jr. Said. “For new equipment designs and redesigns of existing equipment, standard machine components not only save time and reduce costs of the equipment, but they definitely improve the equipment design and function. We can help companies design it faster, build it better, and deliver it more quickly.”

Featuring an in-house machining facility, J. W. Winco provides complete secondary machining of standard machine components and also special custom manufactured component parts.

“We welcome customers’ input and ideas for various components because many of our special machine components manufactured in the past have given us the opportunity to build standards for today,” Robert Winkler said.
J.W. Winco’s production area

As needed, J.W. Winco conducts its own research and produces proprietary products for which it has obtained a number of patents.
“We approach R&D and custom manufacturing on a customer- or market-driven basis,” Robert Winkler noted. “The more common impetus is generally a customer request. From there, we consider whether there is a market for this niche item, and what kind of volume we can anticipate. Other factors include whether we can make it competitively enough, and if it could be sold as a standard part.”

“In terms of research, we’re always open to new ideas, just as we’re always on the lookout for new
products,” John Jr. Noted. “Our core business remains the same—the assembly, modification, and distribution of a wide range of machine components, and Identifying the means and technology that will get that product in and out the door most efficiently.”
J.W. Winco’s production area

The company prides itself on having an experienced staff of technical sales and customer service associates who can address standard machine component and assembly hardware technical questions, as well as assist customers with ordering. In addition, J. W. Winco has earned ISO 9001:2008 certification, demonstrating its commitment to total quality and continuous improvement of customer satisfaction, throughout the entire organization.

“We believe a company that employs a diverse workforce is better able to understand the demographics of the marketplace it serves,” Mark Winkler said. “It is also better equipped to thrive in that marketplace than a company that has a more limited range of employee demographics.”

A company mainstay is a commitment to the environment. This was readily apparent in 2013 whenWinco installed a green roof system on its facility. The company’s conventional roof system was installed in 1993, and it needed to be replaced. Research was conducted on the possibility of installing a fully vegetated green roof system, and a decision was made to move forward.

“The addition of the green roof is part of the company’s effort to be a leader in environmental stewardship by reducing our carbon footprint and managing rain water efficiently, while at the same time cutting energy costs,” Mark Winkler said. “The vegetation on green roofs reduces heat retention, thereby lowering energy usage. Additional benefits included improving air quality, increasing urban green space and wildlife habitat, extending roof life by protecting the roof from harmful ultraviolet rays and temperature extremes, and providing urban green space and educational opportunities.”
J.W. Winco’s production area

The J.W. Winco vegetated roof is viewed annually by an estimated 300,000 online viewers via a webcam broadcast on the company website, www.jwwinco.com. It is also visible on a closed circuit camera system broadcasting live on a large monitor in the building’s main lobby.

Other ways the company has made its buildings and property more environmentally friendly and energy-efficient include retrofitting its entire warehouse with LED lighting, installing skylights and windows to reduce the electricity needed for lighting, and adding motion-sensor lighting in areas of the warehouse used less frequently.

In recent years, the company expanded its recycling effort. Along with recycling plastic bottles and aluminum cans, metal shavings produced in J.W. Winco’s manufacturing process are recycled. The company now uses environmentally friendly water-based coolants on its manufacturing and secondary machining equipment.
J.W. Winco's Product Overview Catalog

The Winklers credit the company’s success to a dedicated and hardworking employee base, exceptional customer service, advanced technology, ecological responsibility, a positive attitude and family-friendly atmosphere.

“We’ve increased our customer base, greatly expanded our product offerings and application niches, enhanced our ability and flexibility to provide a ready-to-assemble finished product, and opened up many new sales channels,” John Jr. Said. “We have always continued investing in all aspects of our business, even when the economy has been tough, while many others in our industry have pulled in the reins on so many of the important elements that keep com - panies in business.

“Taking a friendly and positive attitude to the marketplace is extremely beneficial. We’ve found that a positive attitude is contagious: it spreads everywhere!”

For more information, contact J.W. Winco at 800.877.8351, or visit www.jwwinco.com.

“WE WELCOME CUSTOMERS’ INPUT AND IDEAS FOR VARIOUS COMPONENTS BECAUSE MANY OF OUR SPECIAL MACHINE COMPONENTS MANUFACTURED IN THE PAST HAVE GIVEN US THE OPPORTUNITY TO BUILD STANDARDS FOR TODAY,” ROBERT WINKLER SAID.


American Fastener Journal - July / August 2016
By: Dave Amoroso • Ron Sonntag Public Relations, Inc.

Monday, August 8, 2016

Technopolymer Plastic Lockable Safety Five Lobed Knobs Available from J.W. Winco, Inc.

J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now offers EN 5337.9 Technopolymer Plastic Lockable Safety Five Lobed Knobs, With Tapped Brass Insert, in metric sizes.


EN 5337.9These RoHS-compliant safety five lobed knobs are temperature resistant to 100°C (215°F), as well as resistant to solvents, oils, grease and other chemical agents. To engage and release, the key must be inserted and turned by 180°, creating a formlock between the handle and the tapped insert. Turning the key back by 180° will release the connection. The key can be inserted and pulled off in both end positions, and two keys per knob are included.

The hand knob is made from a special glass-fiber reinforced technopolymer plastic featuring a black matte finish, with the underside plastic cover ultrasonically welded to the handle body. The tapped insert is brass, molded-in, with a zinc die cast lock mechanism, while the key is brass and nickel plated, with a plastic grip.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries.  J.W. Winco’s Web site catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com.

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail atsales@jwwinco.com.

Friday, July 22, 2016

J.W. Winco, Inc. Offers Zinc Die-Cast Hinges with Extended Hinge Wing

J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now offers GN 237 Zinc Die-Cast Hinges with Extended Hinge Wing, Countersunk Thru Holes or Threaded Stud Type, in metric sizes.

GN 237These RoHS-compliant hinges with extended hinge wings, used when wider spacing is required on the mounting surface for the bore holes, have a compact and sturdy design.

The hinge body is zinc die-cast, with either a black powder coated, textured finish or silver powder coated, textured finish. The hinge pin and threaded studs type are stainless steel. Various metric and inch size fasteners and kit packaging available upon request.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s Web site catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com.

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail atsales@jwwinco.com.

Friday, July 8, 2016

Technopolymer Plastic Hollow Knurled Knobs with Stainless Steel Non-Marring Tipped Threaded Studs Available from J.W. Winco, Inc.

J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now offers GN 421.10 Technopolymer Plastic Hollow Knurled Knobs, with Stainless Steel Non-Marring Tipped Threaded Studs, with Brass or Plastic Tip, in metric sizes.

GN 421.10These RoHS-compliant hollow knurled knobs with brass or plastic tips at the end of their threaded studs are used in applications where marks and damage on the workpiece are unacceptable. In clamping applications, the partially protruding steel hub of the knob prevents chipping of the plastic.

The knob body is black technopolymer plastic, with a smooth, glossy finish. The threaded stud is stainless steel,, molded-in, while the tip is brass or plastic.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s Web site catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com,

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail at sales@jwwinco.com.

Friday, June 24, 2016

J.W. Winco, Inc. Offers Zinc Die-Cast Adjustable Friction Hinges

NEW BERLIN, WI -- J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now offers GN 437 Zinc Die-Cast Adjustable Friction Hinges.

The RoHS-compliant hinge body is zinc die-cast, with either a black powder coated, textured finish or silver powder coated, textured finish. The friction cone, which is temperature resistant to 80° C (176° F), is plastic, while the set screw and hexagon nut are steel, zinc plated, with a blue passivated finish.

GN 437The set screw allows the mobility of the hinge to be changed, and it also generates a constant braking torque adjustable across the entire rotating range. The rotation of doors and flaps is inhibited, preventing inadvertent movement. Interlocking two slim friction cones achieves the friction torque, as the large friction surface and the hard-wearing plastic of the friction cones guarantee a long service life with virtually no wear. Due to the structure and the pre-stress of the friction cones, the hinge has virtually no radial play and no play at all in the axial direction.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s Web site catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com and via e-mail at sales@jwwinco.com.

Thursday, June 9, 2016

Stainless Steel Hinges from J.W. Winco, Inc. Resist Tampering

J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now offers GN 129.5 Stainless Steel Hinges, in metric sizes.

GN 129.5These RoHS-compliant hinges are used for doors that are flush with the frame on the outside. Once assembled, they cannot be unhinged. Being mounted from the inside, they are especially suitable for doors and trap doors, which must not be detachable from the outside, as an anti-tamper device.

Hinge body, pin, and washer are available either in stainless steel, European Standard No. 1.4305 (American Standard Series 303) or A4 stainless steel, European standard 1.4408 (American Standard Series 316). Hex nut and serrated washer are of stainless steel, European Standard No. 1.4301 (American Standard Series 304).

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s Web site catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail at sales@jwwinco.com.

Thursday, May 26, 2016

Bull's-Eye levels from J.W. Winco, Inc. Have Mounting Flange

J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now offers GN 2277 Bulls-Eye Levels with Mounting Flange, in metric sizes.

GN 2277 These RoHS-compliant bull's-eye levels are used to check the horizontal position of jigs, machines, devices, appliances, and instruments. The spirit levels are aligned in relation to the reference surface so that the bubble is located inside the marking ring when the horizontal position of the contact surface is achieved.

Housing is anodized aluminum with a natural color finish or black finish. Spirit level element has a glass plastic body, with a colorless-transparent filling. Casting compound is mineral-based. Two types are offered: with mounting flange for bolting to surface, or with mounting flange with collar for inserting into bore holes. Levels have a sensitivity of 30 angle minutes, with bubble able to move by 2 mm.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s Web site catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail at sales@jwwinco.com.

Friday, May 13, 2016

Inch Size Self-Adhesive Rulers Available from J.W. Winco, Inc.

J.W. Winco, Inc., a leading supplier of standard industrial machine components, announced it now offers GN 711 Self-Adhesive Rulers in inch sizes.

GN 711These RoHS-compliant rulers are used to provide measurement markings in a variety of applications on machine tools, woodworking equipment, etc., in industries such pharmaceutical, packaging, and the food industry. They are offered in three versions: stainless steel, .02" thickness, scale etched; white plastic, .01" thickness, highlighted in silver, scale printed; and transparent plastic, .01" thickness, transparent, scale printed. Each version is available also in five different scale sequences.

To apply the GN 711 ruler, remove the protective strip on the back and affix to the surface. The engraved side of the stainless steel version is also protected by a strip of plastic film. Also available are GN 711.1 Indicator Arrows, in each of the three different materials.

J.W. Winco offers an extensive selection of inch and metric size adjustable levers, cabinet U-handles, plastic and steel hinges and locking mechanisms, revolving and retractable handles, hand wheels, hand cranks, tube connection and conveyor components, inch and metric construction tubing, shock absorption mounts, leveling mounts, hand knobs, spring, ball and indexing plungers, jig, fixture and fastening components, retaining magnet assemblies, toggle clamps, metric casters and wheels, universal joints, oil sight glasses, and metric tools for the industrial and commercial equipment industries. J.W. Winco’s Web site catalog, with 3D CAD and online buying, is viewable at www.jwwinco.com.

For more information, contact J.W. Winco at 800-877-8351, by fax at 800-472-0670, on the Web at www.jwwinco.com, and via e-mail at sales@jwwinco.com.

Wednesday, April 27, 2016

GN 927.7 All Stainless Steel Clamping Levers with Eccentrical Cam, with Threaded Stud

Today we're introducing our new GN 927.7 All Stainless Steel Clamping Levers with Eccentrical Cam, with Threaded Stud, in metric sizes.

These RoHS-compliant levers are used for rapid clamping and releasing operations. In contrast to a clamping operation utilizing only threads and a lateral force, these levers permit torque-free clamping via a combined downward vertical and cam actuated motion. The lever has been designed to insure that its movement cannot exceed the maximum clamping position. There are no loose components since all are assembled and mounted in their correct order.

Lever and components are all stainless steel. Type A features an adjustable contact plate with setting nut. Type B has a fixed contact plate. Advantage of the adjustable contact plate is that the distance between the eccentrical cam and the contact surface is adjustable by means of a fine threaded knurled nut. This permits the maximum clamping force to be set by a simple adjustment. In addition this also permits the selection of a preferred lever position in relation to the clamping lever pin.

With these clamping levers, thrust forces of up to 8 kN (1800 lbf) can be obtained. The shape of the clamping screws/nuts prevents the formation of moisture build-up. The Type B version also seals the mounting hardware bore holes and threads. The material and design of these clamping levers make them ideal for hygienic applications. A tapped version is also available.

To see our entire selection of cam units and cam levers, visit Section 11 of our online catalog.

Wednesday, April 13, 2016

GN 854 Latch Clamps with Trigger Function

Here's another innovative new product we recently introduced: GN 854 Latch Clamps with Trigger Function, available in metric sizes.

The outstanding feature of these RoHS-compliant latch clamps is their highly robust, sturdy and compact design, permitting their use under demanding conditions, e.g. exposure to high temperatures, dust, spray mist, etc. The specially designed catch allows the forced loosening of the clamp, by the clamping arm moving the pulling latch forward, e.g. for separating mold halves.

Clamping bearing/clamping arm are made of forged, weldable, blank steel. Pulling latch/bearing pins are steel, St 37, blank, and catch is sheet metal steel, blank. The clamps are available with bore for gear lever handle or with clamping arm. The former version is operated with a gear lever handle which is plugged into the latch and pulled off after operation. This saves space and has the added advantage that the gear lever handle is not exposed to adverse ambient conditions, e.g. becoming too hot to operate.

The catch can also be mounted using screws or bolts. If required, clamps and catches are also available as separate parts; for replacement, the bearing bolt is easily dismantled.

To see our full line of Toggle Clamps, visit Section 15 of our online catalog.

Wednesday, March 30, 2016

GN 7403 Aluminum Breather Strainers with Stainless Steel Mesh

Today we're introducing GN 7403 Aluminum Breather Strainers with Stainless Steel Mesh, available in metric sizes.

These RoHS-compliant breather strainers are used in enclosure and device construction. Mounted into the wall of the enclosure, they ensure pressure equilibrium between the inside of the enclosure and the outside. The outside diameter of the enclosure with the recessed hexagon matches the bolt mounting holes for DIN 3852 threaded pipe connectors.

Any dirt and dust particles carried by a particular medium (such as air or a gaseous substance) are prevented from exiting. This protects the insides of sensitive devices and machinery parts from dirt and pollution and also protects the environment from any exiting dust. Sealing ring is embedded in a radial and plane-sided recess which makes the seal captive, and prevents it from being squeezed out during tightening.

Strainer body is aluminum, with stainless steel mesh of 100 or 500 ┬Ám. Strainer bezel is glass fiber reinforced plastic (Polyamide PA), with seal of NBR synthetic rubber (Perbunan). Versions with both metric and BSPP parallel threads are available.

To see our entire line of Fluid Level Indicators and Components, visit Section 12 of our online catalog.

Wednesday, March 16, 2016

GN 53.1 Plastic Retaining Magnet Assemblies, Disc-Shaped, Without Thread

Greetings! Today we're sharing with you about our new GN 53.1 Plastic Retaining Magnet Assemblies, Disc-Shaped, Without Thread, which are offered in metric sizes.

These RoHS-compliant components are a shielded magnetic assembly. They are primarily used for holding drawings and the like. The ND magnetic material is characterized by a high adhesive force.

Housing is plastic, available in gray, white or red. Magnet is neodymium, iron and boron, NdFeB (ND type). Sizes range from 18 to 40 mm in diameter. Temperature resistant to 175 °F (80°C).

To see our full line of Retaining Magnet Assemblies, visit Section 11 of our online catalog.

Wednesday, March 2, 2016

GN 132.5 Stainless Steel Two-Way Connector Clamps

Today we'd like to tell you about our new GN 132.5 Stainless Steel Two-Way Connector Clamps, available in metric sizes.

These RoHS-compliant connector clamps have clamping bores machined and designed for GN 990 construction tubings or DIN 2391, DIN 2395, and DIN 2462 respectively. Clamps are made of stainless steel, with clamping bores machined. Carriage bolts are DIN 603, A2 stainless steel; cap nuts are DIN 917, A2 stainless steel. Type A features sealing, while Type has plastic washers (Polyacetal POM) and edge ring of Silicon, 40-60 Shore A.

The shape of the clamping screws/nuts prevents the formation of moisture build-up. The Type B version also seals bore holes and threads. The material and design of these connector clamps make them ideal for hygienic applications.

To see our complete line of Tube Clamping Components, visit Section 16 of our online catalog.

Tuesday, February 9, 2016

GN 252.5 Stainless Steel Threaded Plugs

Here's another new product we've recently added to our immense line of standard machine components: GN 252.5 Stainless Steel Threaded Plugs, available in metric sizes.

These RoHS-compliant threaded plugs can be used as spring retention units or as plugs to keep debris from entering into critical threaded areas. The PRB thread coating (polyamide allround coating) acts as a clamping lock, preventing the locking screw from inadvertently being loosened and becoming detached.

Plugs are made of stainless steel, European Standard No. 1.4305 (American Standard Series 303). They are available with or without thread coating (polyamide overall thread coating). Thread sizes range from M12 to M27.

To see our full line of Fluid Level Indicators and Components, visit Section 12 of our online catalog.

Tuesday, January 26, 2016

GN 1130 Steel Lifting Pins

Today we'd like to tell you about our new GN 1130 Steel Lifting Pins, available in metric sizes.

These RoHS-compliant lifting pins are carrier elements designed for fast and easy use. Pressing the red aluminum button will release the locking effect of the locking balls, allowing the load pin to be moved in or out of the holding bore hole. The shackle rotates by at least 180°, with a safety flange fitted as a safeguard against inadvertent operation. Depending on the direction of pull, the ball load pin may move freely by 360° in the holding bore hole.

These lifting pins alleviate the need to have lifting gear (e.g. load rings) permanently with the workpiece. Holding bore holes with d1 H11 tolerance are adequate for use.

Stud and shackle are made of heat-treated, manganese phosphated steel. Push button is red anodized aluminum. Spring is made of stainless steel. Lifting pins can support nominal loads from 1.5 to 4.8 kN.

To see our full line of Lifting Eyes and Load Rings, see Section 11 of our online catalog.

Tuesday, January 12, 2016

GN 2424 Aluminum or Steel Cam Roller Carriages

Today we're introducing our new GN 2424 Aluminum or Steel Cam Roller Carriages for GN 2422 Cam Roller Guide Rails, available in metric sizes.

These RoHS-compliant carriages are combined with GN 2422 cam roller linear guide rails to build roller guide systems. They are used in mechanical engineering or jigmaking for the linear movement of plant equipment. Depending on cam roller carriage type, these can be mounted in axial or radial direction to the roller axes. Also depending on rail type, matching wipers are mounted, with type N featuring additional sealing lips in longitudinal direction.

Base body is offered in aluminum, or steel with zinc plated, blue passivated finish. Rollers are made of anti-friction bearing steel, hardened, with balls mounted. They are dust and splash water protected by (2RS) NBR seals and have permanent lubrication. Wiper is gray plastic (PUR) with zinc plated steel insert. Three types are offered: Normal cam roller carriage with central arrangement, radial cam roller carriage with lateral arrangement, and narrow cam roller carriage with central arrangement. Meanwhile, carriages may be purchased with wiper for either fixed bearing rail (X-rail) or floating bearing rail (U-rail).

To see our complete line of Linear Guide Rail Systems Components, visit Section 9 of our online catalog.
